Hi all, I've been working on my boat and thought it a wise decision to touch base to benefit from anyone else's advice. I have the following setup: Shore Connection Socket (Charges batteries from 220v shore ) 3 Pin 220v Shore Connection > 50A Fused Isolator Switch > Automatic Inverter/ Charger > Consumer Unit > the rest of the boat. 220v Solar PV to Leisure Batteries (Powers 12v leisure batteries from solar panel energy) 215w Solar Panel > MPPT Charge Controller > Automatic Inverter/Charger > Inline Battery Fuse > 2 x 12v Batteries in Parallel. 12v Battery Connection (Powers electrics when not plugged into a shore connection): 2 x 12v Batteries in Parallel > Inline Battery Fuse > Automatic Inverter/Charger > Consumer Unit > to the rest of the boat.

Hi all Looks needing to use power tools on the 2kw pure sine inverter. When running these large loads with high inductances how wise is it to push the inverter? Or should leave a good over head like push no more than 1.5kw? Thanks again James

I'm in the process of taking over maintenance of a lovely narrow boat that my dad's getting too old for unfortunately. I'm very much a newbie and the kindness of local boat people has got me pretty far. However, while I've managed to install a new leisure battery and so have power, I need to do some maintenance that means plugging in a drill, but none of the 240v sockets work. I've tried flipping the switch on this control, but it had no effect. With each setting I continue to get power from the battery, but never via the sockets. Am I warm, or barking up completely the wrong tree?

Hi, I have a twin alternator set up (with a Merlin battery management system) to charge 1x110a starter and 3x110a domestic batteries. The alternators are sometimes charging (14.05ish volts on the multi-meter for both) and sometimes not (12.5 - 12.8ish volts for both). Any ideas on what would cause them both to stop charging while the engine is running?

Hi all. We have a air cooled SR 3 with one starter and 3 new 130ah leisure. We are noticing that despite cruising for 5-6 hours we are not getting above 12.6 at most. We are running a 2000w inverter and 240v fridge. We have a single alternator charging the batteries. Even if we turn off the inverter when cruising it doesnt get any higher. Any ideas why we are not getting a full charge as we are finding we can barely last 24hours with not alot running.

Can anybody help me sort this out? When I bought my boat it came complete with a non functioning Eberspacher D5W. I was told it needed a control board and we agreed a discount on the basis that it wasn’t working and that the part has being sought then when it arrived it would be forwarded to me. However when it did arrive some 3 months later the vendor said I would have to pay for it which is not what I thought we had agreed. I thought the discount was for my inconvenience and the fact I would have to fit it myself or pay someone to do it. Long story short I still have a non-functioning Eberspacher. I have posted 3 pictures of what I have. I do not need automation or remote control or a timer, I am happy to turn it on and off manually. It would just make more sense to me to be able to brew up a tank of hot water without running a 2 litre Diesel engine for a couple of hours. As you can see from the pictures I have a heater, a wall mounted box and a pull switch on a knob. When I connect the heater to the box with the plug and socket by the heater unit (both present and correct) and turn it on nothing happens. So can anyone tell me what is missing and or what I need to do to make this kit functional. In anticipation of your useful advice and replies, Thank you. David

Hi all. So- new batteries, new inverter, added 2x100w solar panels and STILL off grid power seems to drain. Take last night. Had to run engine for 2 hours to get to 12.6v. Bed time 12.3v. This morning 11.3!! Only thing running is the fridge at 35w and the inverter on power save mode at 0.2w. Any thoughts?? Would be welcomed.?

Hello, I need some advice please - I'm slowly getting my head around things but struggling with electrics, so please excuse the very basic questions! Spent ages searching for the info, but none the wiser... I don't have an inverter on my boat, I'm currently on shore power. I'm going to leave the marina and start cc'ing. What would be the best option for being able to charge a phone sometimes & maybe plug in a radio & a lamp? I don't have any other appliances to run. There are a couple of 12v plug sockets & the rest are 240v. Can you get something to plug into the 12v socket to allow you to plug in a 240v appliance? Would one of those USB car charger things be best for the phone charging? Do they convert 12v to 240v? Basically, I don't think I need a big inverter installing, I don't need to use most of the sockets, or use much power. But I don't know a simple solution to this. Sorry if these are silly questions, I appreciate any advice

Hi All, Can anyone recommend a good electrician near Milton Keynes please? Kind Regards Adam

Before embarking on installation of my AC system, if anyone could share any information on the following I would appreciate it. According to the RCD (recreational craft directive) is the following AC system acceptable? (I shall start form shoreline connection to AC outlets) Shore line connection plug fed into an RCD (residual current device) within 0.5 meters form the plug, the RCD shall be housed in a waterproof box next to the plug (a garage box). This RCD shall feed into two single pole MCBs, one connected to the diesel immersion heater, and the other connected to the inverter. Out of the inverter I propose to feed another RCD, housed within the electrical cupboard which shall feed two other single pole MCBs, a 10A MCB for a ring circuit of ac sockets (12 sockets, which I know is a large amount for one ring, but with 2.5mm cable and a smaller MCB this will reduce loading the sockets with the full whack of the 3KW inverter), and the other 12A MCB for a washing machine. My main question is... Does the galvanic isolator need to be connected at both RCDS or would connecting it to the first RCD ground the inverter through the galvanic isolator? Or do both RCDs and Inverter require grounding through the galvanic isolator. I will also be connecting the inverter to the batteries but that shall be for another day. Thanks, Will

We have a Beta 43 engine with twin alternators. The domestic 150A alternator charges four domestic AGM batteries which are now just over 2 years old. The boat and the alternator are nearly 9 years old. Normally the domestic alternator charges at a voltage ranging from 13.8 to 14.5 volts. On a recent trip it was charging at 14.8 to 15.2 volts. The batteries were not hot after several hours at this charging rate. I have no way of measuring the current at which it was charging. Should I be worried about this and what might be the reason? We have no separate regulator between the alternator and the batteries. We do have a solar panel (100W) charging the same four batteries through a regulator. The solar installation is also about 2 years old. Any ideas?

Hey guys and gals, I'm sure it's something simple I've done wrong here but I've wired a 12v socket that has 3 cigarette style sockets and 2 usb sockets. I've tried wiring it in to two different connection points, where the lights are wired to and when I connect some things, especially my 12v laptop adapter, all the lights flash like a rave. Does anyone have any suggestions? Do I need to wire something in between to stop the "surge" or am I being too simple with my wiring? Thanks in advance.

Hi, the BSS says that cables between a battery and - another battery, or - an inverter over 1000W, or - a master switch, - etc, should be "sufficiently" big: "must be approximately 25mm2". To me, "approximately" means "as long as it's really safe". With two leisure batteries of 110Ah in parallel, is it safe to have a 16mm2 cable between them? I have seen 16mm2 cables on several of my friends boats. I am wondering whether I should propose to change their cables to 25mm2. Also, if a cable to the master switch is 16mm2 and has a 50A fuse, that should be safe and hence pass BSS, right? PS: Woops, I cannot change the title anymore, it should be "25mm2". Mistyped.

Hello all, Sorry for the long post and the rather basic questions, I am a genius with computers but a complete novice when it comes to boats. I have recently become the owner of another cabin cruiser after receiving a second chance offer on eBay and am after some advice/guidance on renovating her. This was the original advert: 20ft Cabin Cruiser Chenise is a great little family cruiser ideal for both river and sea, she has a forward cabin equipped with sink, work tops, bench seating with storage under, top hatch with integrated fan and two under counter cupboards. The V shaped hull is designed to form a bed with the appropriate cushions and boarding. A 12v inverter is fitted to power 240v equipment via the solar charged battery such as dvd player, radio etc. The rear deck has a full canopy witch has recently been re-proofed, the flooring is decking planks with an access panel to the electric bilge pump. Bench seating with loads of storage under including manual bilge pump. Water from the bilge and sink is ejected via built in ports. Steering wheel and remote controls for the main engine, cabin door with padlock clasp, window and port hole with removable panel. The decks have anti slip plates, bow rails, bow anchor roller, tie off points etc. 2x nav lights and 1x rod holder. Main Engine. Mercury 40hp (pull start) connected to remote steering and controls, last serviced November 2014. Great motor and moves her along on both river and sea. (see below) Auxiliary Motor. Mariner 2hp. Small unit but pushes her along to get you home if main engine should fail. Recent service with new impeller, oil etc. Chenise is a great boat and has given us some good family weekend fishing / cruising etc. She is currently moored at Heybridge Basin in Essex offering great cruising and fishing and access to the sea via the manned sea lock. It is possible to sail to Chelmsford stopping off at supermarkets and pubs on the way for great family days out. (Moorings available) Chenise was bought with the intention of a full refurbishment but enjoyed her so much we never got round to it and just enjoyed her “as is”. We have now purchased a larger boat hence this sale. Bad Bits. Used boat 2 weeks ago and all fine but now can’t start main engine, started to rub down cabin but never finished. Needs some TLC but will come good. Viewing welcomed and encouraged. Was purchased in this location so no trailer. If you buy to remove she will need to be sailed through sea lock to a slip way about 15 min sail at the cost of £30 to use slip way. (aux engine will get you there) Less than 10 feedback score please contact me before bidding! UK buyers only. You bid to buy, not view or haggle so please come and view if you have any concerns as this is now relisted and I really need the mooring for new boat Pictures can be viewed here: http://s287.photobucket.com/user/southeastbikers/library/Chenice?sort=3&page=1 The pictures are from two adverts, the original sale in August, which apparently fell through (and then the Mercury outboard unit stopped working) and how it looks now with the yellow/green interior, sink, and worktop units. She is cosmetically a tidy cabin cruiser but I need help with creating a 'plan' of things required to have her canal/seaworthy as I wish to take her from her current moorings out of the sealock and around to other rivers/routes (she is currently on a 13mile navigation that does not connect to anything else) So far I have secured the rights to her moorings and insured her with AIG (Insured her as a Microplus, although any confirmation would be great!), and thankfully at this stage she does not require a BSC due to being moored at the Basin, but obviously this would be necessary to take her on either the current navigation or any other inland waters. My first priority is to have the outboard repaired and hopefully have this running, having no experience of outboards and limited experiences of boats in general this will certainly be an adventure/challenge, I am currently attempting to contact the previous owner to obtain the 'auxilary engine' mentioned in the advert as this was not left on the boat, nor were any batteries or other marine items. My questions are: The boat apparently has 2 navigation lights but I have not seen a fuse panel like we have on our other boat, infact I am not sure how any of the electrical components are being powered so would like to fit a fuse panel, are these panels difficult to wire in yourself and do they need to meet any sort of requirements? What one would I require? According to the advert, there was a small auxilary engine (which we are still attempting to obtain), other boats we have seen have these mounted on a square block that protudes from one side of the transom, but our boat does not have this, is there a specialist mount we require to mount this next to the main engine? I aim to kit out the interior further, do I require a particular foam/wood for this purpose? I am not a fan of the padlock/clasp cabin lock, are there any issues with fitting a general yale-type door lock to cabin doors? I'm sure I will come across more on a closer inspection over the weekend, but all help for now is much appreciated!

Hi all, For a while I've been toying with the idea of buying a narrowboat to continuously cruise along the London Canals, for a few weeks or so I've been doing a fair bit of research but for some areas I still haven't found the answers I'm looking for so thought I'd turn to you guys to see if you can help me out at all! Apologies in advance if some areas have been discussed already and also, if any of the questions sound silly... I really am a complete newbie to this... 1. As I mention - I'll be CC along the Canals in London, so have been researching what distance as I need to travel each week, obviously don't want to take the mick and want to stay on the right side of Canal and River Trust. However, their website isn't totally clear on how far - all I can see is that in a years licence, 15-20miles is expected, which seems more than fine. But how far is the minimum? Just for an example, say I started in Little Venice and was travelling East, how far would I need to travel to satisfy the Canal and River Trust for say one weekend I didn't want to travel 'that' far? 2. Which brings me on to my next point - as I read, each 14 days would be the time I top up water, which would top up my batteries (as I'm moving) and usually empty the loos out. May seem like a silly question but are these water points at regular intervals? Similarly, to electric points? (if I needed it half way) Also, are loo-emptying-places at regular intervals also? 3. Again, brings me on to my next point of water storage tanks and electricity batteries... my budget is around 25k and aiming for around a 40ft-er trad steel narrowboat so from what I've seen, many don't have a tank or seems quite small. If so, can this be retrofitted and to what cost? I understand becoming more frugal is all part and parcel of it (which I'm excited about) but for say a 10/15minute shower a day - what sort of tank should I be looking at to tide me over for two weeks? However, I guess this would hinge on question number two! In terms of electricity, I don't watch a lot of TV but would like to charge my phone, listen to music, have lights! Where should I even start with what to look for to tide me over 2 weeks again? 4. I guess this question is more to the nitty-gritty when I view but what are the main tips/points you'd recommend to look out for a bad conditioned narrowboat? Is there such a thing? Don't mind buying something that requires a bit of modernisation but in terms of 'behind the scene' stuff, what do I look for when looking at an engine? At the electric board? Heating system? Or should this all be taking care of at survey stage? Anyway, I think that's probably enough for now on my first post. I really would appreciate any tips/answers - no matter how big or small! Really excited to be buying - just need to get my head around it all first!! Speak soon, Nat

Hi all. I should begin by saying that I'm not the most talented when it comes to matters of electrickery, so please be gentle with me if I've overlooked something glaringly obvious! I'm hoping to be able to pick someone's brains about a problem with my inverter/charger. It's a Studer Compact C-1312, and I'm also connected to shore power. The other evening, the inverter suddenly went off - completely dead, no lights on the display panel, and won't come back on. I'm also not getting any 240v in the boat through the shore line, and neither are the batteries charging (apart from when I run the engine). The 12v still works fine (water pump, lights, fridge, freezer, 12v sockets etc), and I've checked that the shore power hasn't tripped. The shore lead is also fine, and there are no obvious loose wires anywhere that I can see. I've also got a Travel Pack, and I get 240 when I run that, but nothing otherwise. I've got a manual for the Studer, but the English isn't the best (especially for a numpty like me!). I'm hoping it's something simple (and cheap!) like a fuse blowing, but I can't see any fuse holder on the outside of the casing. I haven't yet removed the cover, but does anyone know if this inverter has a fuse inside? Or any other possible causes/solutions? Many thanks in advance

Hello, I have a Lugger generator (Model number: M673LD3.5) and it keeps tripping out (or appearing to) when i switch to generator input - there isn't a load on it at that point and the fuse is intact. Any ideas? Does it just need a service? Thank you for any help

The use of an earth return for onboard electrical equipment is discouraged as it is a potential source of hull corrosion ? YET most of us use high power alternators with exactly that, so what's the difference ? If a few mA from a radio will cause damage, think what 100A will do !

Hi there, I'm about to buy a boat which has been fitted out (electrics-wise) for shore power, with loads of 240v plug sockets everywhere, TVs, Kettles etc, but we don't anticipate or want to be hooked up at all. What I was wondering was if anyone has had experience in changing this sort of setup over to a 12v, battery-based setup, and what challenges they faced whilst doing so. Is it just a case of removing the external hookup point, connecting the internal wiring to the existing 12v loop (which runs the cabin lights etc) and replacing the 240v sockets with 12v ones? Maybe keep one or two and run through a separate, inverter-containing loop from the battery bank? I don't expect it to be that easy but hopefully it won't mean ripping the walls apart! Cheers, Alistair

Hi All, Does anyone out there have a SM Hudson boat 57' plus, with engine room and boatmans cabin built within say the last 5 years and would allow me to view there boat to help with a boat build on my unfinished Hudson shell? Would be very much appreciated. Regards John

Does anyone know what the diameter/pitch is on an A127 shaft thread please? I am pretty sure it's some variety of M17 but can't remember whether it's M17 x 1.0 or M17 x 1.5, and I don't have the alternator handy to measure. N

When connecting a new bilge pump direct to the batteries, my spanner accidentally touched the the hull whilst loosening the positive battery terminal. This resulted in a small, but very definite spark, which puzzles me. I didn't think there was any contact between batteries and hull, so why would I get a spark? I do not have any shore power circuits (do have a small inverter though). Does this spark indicate something might be wrong? Any enlightenment would be appreciated.

Hi there, first post on here after reading for a few years! we are currently planning our first fit out of a new boat! I have done all calculations necessary and calculated cable diameter however one thing that i feel like i need some advice on is the actual circuitry of the boat. I have put together a quck schematic of what i am currently thinking in terms of the installation however it would be great to get some feedback from you experianced boaters! any advice is more than welcome and thank you in advance! Alex Full Electrical Schematic -BS EN ISO 101332017 & BS EN ISO 132972014-.pdf

Hi, I have just looked at a 36ft Springer (perhaps early 80's) narrowboat for sale, priced at 10,000, as a project boat. No survey yet - owners have had her for 3 years, in those years they have replated on both front and stern after a survey, and blacked and annoded once (now due for renewal) The project: 1. Pre-purchase: Survey + It is due blacking, annodes and engine service (potentially the costs of this, and any replating needed, could be deducted from 10,000 boat cost) 2. Interior Hull: Need to create access in the floor to the interior hull as it there is currently no hatch etc. - Whilst doing the floor, thought would be a good idea to swap (apparently lumps of metal) ballast for engineering blocks, and, do work on the interior steel hull if needed (wire cup brush, rust treat with Vactan, and overcoat with something - bilge paint OR red oxide???) - Then insulate, plywood boards, and wooden board flooring. 3. Panelling: Taking down wall and ceiling boards which have been B&Q bodged in, to be able to redo with nicer wood, but most importantly, electrics and plumbing. 4. Wiring: There is wiring for 12v and 240v, however 240v is not plugged in at the moment, and the owners are running off solar (owners don't trust the wiring) SO would need completely re-wiring the solar (as it is currently just strung around the boat), utility battery for ceiling lights, 12v sockets and 240v sockets, and waterpump for shower/water. 5. Plumbing: There is also plumbing, but they currently don't use as they removed the old watertank, and currently run off a jerry can of water for the sink, and a cassette toilet. The plumbing also currently runs under the floor, so all old plumbing needs to be ripped out, and replumbed in the wall cavities - would like to plumb in sink, shower and potentially septic tank toilet, and then need to get a new watertank. 6. Other Misc: There is a working gas oven and hob, which seems to be fine and functional, so maybe gas is ok? Also a good, working coal/wood burner. Although engine needs a service, she ran well, when they took us for a 1 hr cruise, i think it is a Lister aircooled engine. So, if the survey all went well, does this sound like too much - In all honesty this would be my first narrowboat, but I am on a budget, hence only being able to afford budget boats. Time is not an issue, although being able to live in it by spring would be great. Main questions; - does the tactic to restore the inner hull sound like an ok approach, if it needed doing? What is the realistic expectation for the steel interior hull of a 80's Springer? - is wiring/plumbing possible to do myself, or is it needed to have a professional for BSC and insurnnce? In which case, how much could i expect for full plumbing/wiring? - what work could i expect to do myself, and what should i look for quotes for? Any advice will be HUGELY appreciated in terms of costs expected, or time taken, or regulations to adhere to when doing up a boat. This boat, technically is liveable, as they have been fine for 3 years, but needing this work, what price for it would be realistic? Thank you!

Hi All, I have a ford 1.8xld with Bosch alternator, also the boat has a smith industries tacho, which has never been connected. I have searched and found links from other sites, as I understand it the Tacho is wired to ground and to the 'W' terminal of the alternator. See pics. As you can see from the alternator picture, the 'W' terminal appears to be missing, I am assuming that I will have to connect my own terminal her, probably by soldering. Is this correct ? The second picture is from the back of the Tacho. Assuming this is the wiring diagram, single ind is a single alternator setup, dual ind, for a dual alternator setup. So if I am reading correctly, 'W' connector from alternator, to pin 1 of Tacho, pin 2 of Tacho to Ground. And now if I wanted to connect the second Alternator, then the same for pins 3 and 4 ? If any one can just confirm or deny, been a while ( 18 years ) since working on this type of equipment.
