  1. Jen-in-Wellies

    Middle level weed nightmare

    That type of weed is a nightmare. On my boat it wraps round the propeller shaft, rather than the propeller itself. The propeller becomes ineffective when the ball of weed in front blocks any water getting to the prop itself. There are weed cutters for sale that fit around the shaft, but never tried one and no idea if they help. They are sharp and can cut you when you do have to stick your hand down the weed hatch. The only time it has ever defeated me completely was on the Chesterfield Canal, just outside Retford a few years back. Clear the weed, go another couple of yards, clear the weed, repeat till I gave up and reversed a mile back to the previous winding hole. Met a CaRT contractor who had spent weeks working a weed removal boat there with little effect. Jen
  2. Jen-in-Wellies

    Big sofa, little door...

    I have a Nabru that I find is perfectly comfy. This is something where one persons idea of ideal is not the same as anothers, so the only way you can tell is to try one yourself. Be careful on measurements of the sofa, not just getting it in. If you have a narrow beam boat, then watch for height compared with the gunwale so it can slot underneath and overall depth, so you can actually get past it. Most sofas for houses are far too big for narrowboats. If you have a wide beam, then your options are wider too (see what I did there?). 😀 Jen
  3. Jen-in-Wellies

    Appropriate solar

    Each panel will have up to 48V on it when unloaded, but up to around 36V at optimum power. If all the panels are in series, then the total will be between 36x4 = 144V and 48*4 = 192V. However the solar controller has a maximum input voltage of 150V, so there is a high risk of exceeding this, or pushing towards the maximum and damaging the controller. If the panels are in parallel, then the voltage will be that of one panel, 36 to 48V in bright sun. However the current through the wires will be four times as high and can lead to resistive losses. A mix of series and parallel will give a voltage of 72 to 96V and mid range in the current. This is what I would go with if it was me setting up this array. Pics below. Note that some of these voltages are enough to give you quiet a jolt. Do your wiring with good opaque blankets covering the panels and take precautions. Jen
  4. Jen-in-Wellies

    Appropriate solar

    Looks OK. Monitor and controller matched to the capacity of the panels. All the connectors splitters, wires and cable glands you are likely to need for a neat installation. How are you planning to split the panels, series, parallel, mixed series and parallel? It'll probably need a few other connectors for the connection to batteries. Jen
  5. Jen-in-Wellies

    LED headlights.

    The only incandescent bulbs now left on my boat are in the navigation lights and the tunnel light I use for tunnels with two way working. The super bright LED tunnel light I originally made for Standedge, is restricted to tunnels with one way working at a time. Jen
  6. Jen-in-Wellies

    Cheap Engine Hours Meters?

    You could piggyback it. The one we are considering is to replace a dead LCD hour meter built in to a working rev counter, so similar. On an Isusu panel too! Easiest way is to connect - terminal to the boat negative and the + to ignition switched 12V from the On position terminal on the key switch. This isn't exactly the same as engine on time, but close enough for most people, including me! For absolute accuracy you could include a changeover relay fired from the engine oil pressure switch, so the hour meter only runs when ignition is on and the engine has oil pressure, so is running. To much faff I reckon. Jen
  7. Jen-in-Wellies

    Cheap Engine Hours Meters?

    I agree. The majority of electronic stuff is made in China, regardless of the nationality of the company whose name is on the box. Most of it is excellent quality, especially things made for larger companies to standards that they provide and check up on. This is as good as, or better than anything you can get made elsewhere. However there is a proportion that is very nasty indeed, made by shady, fly by night outfits. They skimp on component quality and manufacturing, giving something that will fail in a short time. Question is, how can you tell? One way is someone elses personal experience. The reason for wanting to get it right first time and not just take a punt is that this is going in to a panel for another neighbour. The panel aperture will be made to fit it, so may not suit another instrument. Jen Jen
  8. Jen-in-Wellies

    Cheap Engine Hours Meters?

    That is more down in the price range of the Ebay ones. RS stuff is usually good, though the price is often high, which suggests that the Ebay price may not indicate poor quality. Jen Edited to add: The Ebay one I linked to is nearly identical to the Kubler one RS sell for £24.23 ex VAT. The only difference I can see is that it doesn't have the Kubler name, or a CE mark on the label on the back. Either it is a knock off, or made in the same Chinese factory after hours, or one for the non-European market.
  9. Jen-in-Wellies

    Cheap Engine Hours Meters?

    Engine hours meters with mechanical numeral movements from the usual suspect Chandlers cost around the £50 mark. There are Chinese ones for sale on Ebay for around £8, plus / minus a pound or two. Has anyone got any experience of these? Are they reliable, or should we stump up the extra for an expensive ones? "You get what you pay for", or "marine surcharge"? Thanks, Jen Another cheap Ebay tat question. We seem to be having a lot of these.
  10. Jen-in-Wellies

    Alternator wiring

    Well spotted. In my defense, I was trying to zoom the picture on my phone! I've used two 15 ohm 5W resistors in series to give 30 ohm in parallel to an LED succesfully, which lead me to see 47R, not 4R7. Jen
  11. Jen-in-Wellies

    Alternator wiring

    If no one here can help with the bulb type, take it to a local motor factors. If you can, find one with a knowledgeable staff member who can cope with you not being able to give them a car registration number. They should be able to help and get you a couple of spares for a few pennies. Jen
  12. Jen-in-Wellies

    Alternator wiring

    The ceramic block is indeed a resistor. It is 47 ohms, which is about the reistance of an alternator warning bulb, so it has probably been fitted to do the bulbs other job of energising the alternators coils so they can start charging. I don't know the bulb type in the other picture, but it looks very small and may not pass enough current to get the alternator energised, hence the low value resistor has been added. This is a common modification when people fit LED alternator warning indicators, for the same reason. If the rwisitor was needed before, then it will need replacing as well as the bulb. The wire may well have broken from vibration. It doesn't look well supported. Jen
  13. Jen-in-Wellies

    Kayak storage

    The high strength Neodymium magnets that are available now can provide good holding power without having to drill, or weld the roof. I have solar panels fixed this way and they have survived several winters worth of gales. Another advantage is if you do go under a too low bridge, they may prevent damage by coming away, rather than bending, or breaking something. Jen
  14. Jen-in-Wellies

    Digital Instrument Panel

    Thank you! The panel is now in and so far, working OK. Don't have a photo yet of it installed. For anyone interested in doing something similar, here are some of the design decisions and circuits used. As has been mentioned before in this thread, boats are electrically very noisy environments. Pumps, motors, relays, alternators, radios are all putting noise and voltage spikes in to the supposedly DC wiring. Delicate low voltage, low current electronics needs protecting against this if weird results, or device destruction is to be avoided. I stole some ideas from the early Bedazzled LED's I have on my boat and also from the Megasquirt project, which is an open source vehicle engine management system. These products have been designed for boat and the similar automotive environment. There is a 22V metal oxide varistor on the 12V input into the 12V to 5V DC-DC convertor. This safely dumps any high voltage spikes, either negative or positive to earth. Protecting the 5V Arduino there is a 5V transient voltage suppressor on the output from the DC-DC convertor. There is another on the resistor voltage divider in to one of the analogue inputs used to measure boat voltage. There are capacitors on the digital and analogue input lines to filter out any high frequency signals induced in to the lines. Most resistors are standard 5% tolerance carbon film. The ones used for voltage divider resistor networks are 1% tolerance metal film type. I've attached pictures of various input circuits below. Also below is the sketch for the Arduino Leonardo for anyone who is interested. Feel free to copy and modify to suit. All this stuff will almost certainly need altering to suit the senders on your boats engine. Jen /*A digital instrument set for boat Delta Lady. Written by Jen-in-Wellies, June-July 2018. Displays on a 20x4 character LCD using an I2C interface adaptor. Uses an Arduino Leonardo PLC as this doesn't use analog-in pins for the IC2 interface, like the Uno and gives six available for analogue inputs, instead of four. Displays RPM, water temperature, oil pressure, voltage and fuel level. Displays warnings when oil pressure is too low or high, water temp is too high, voltage is too low or high and fuel level is too low. Lights LED's and sounds buzzer for these warnings as appropriate. Automagic day/night LCD backlight illumination using Light Dependent Resistor (LDR). */ #include <LiquidCrystal_I2C.h> //Library for liquid crystal displays driven by I2C two wire bus #include <Wire.h> //Library for I2C 2 wire bus to drive the liquid crystal display. #include <EEPROM.h> //Library so EEPROM can be used to store engine hours. /* SDA to the I2C adaptor goes to SDA pin on the Leonardo and SCL to SCL pin These are also on pins D2 and D3, so don't use these for anything else. Similarly, pins D0 and D1 can't be used as they are also for serial data when debugging.*/ LiquidCrystal_I2C lcd(0x27, 20, 4); //Address 0x27, 20 characters by 4 rows. //Define variables for analog inputs. int tempIn = 0; //Temperature input from analog in. 0 to 1024. int oilIn = 0; //Oil pressure input from analog in. 0 to 1024. int voltIn = 0; //Voltage input from analog in. 0 to 1024. int rpmIn = 0; //Engine rrpm input from analog in. 0 to 1024. int dieselIn = 0; //Fuel level from analog in. 0 to 1024. int ldrIn = 0; //Cabin ambient light level from analog in. 0 to 1024. //Define variables for digital inputs. int oilDin = 0; //Oil pressure switch input. /*Calculated values to go to LCD. Floating point for required precision for calculation and display Except LDR, where it isn't important. */ float tempOut = 0; //Calculated water temperature. float oilOut = 0; //Calculated oil pressure. float voltOut = 0; //Calculated engine voltage. float rpmOut = 0; //Calculated engine RPM. float dieselOut = 0; //Calculated fuel level. //int ldrOut = 0; //Output to LCD backlight. byte hoursAddress = 0; //EEPROM address to store engine hours. float engineHours; //engine hours stored in EEPROM hoursAddress //Define time measurement variables for updating engine hours. uint32_t ts1 = 0; uint32_t ts2 = 0; //Define analog input pins int tempPin = A0; //input from coolant temperature sender. int oilPin = A1; //input from oil pressure sender. int voltPin = A2; //input from 12V system voltage divider. int rpmPin = A3; //input from AC rpm sender bridge rectifer. int dieselPin = A4; //input from fuel tank sender. int ldrPin = A5; //input from light dependent resistor. Ambient light. //Defining output digital pins. int oilWarn = 4; //Oil pressure warning LED pin. int tempWarn = 5; //Water temperature warning LED pin. int voltWarn = 6; //voltage warning LED pin. int dieselWarn = 7; //Low fuel warning LED pin. int buzzwarnA = 8; //Warning buzzer output pin A. int buzzwarnB = 9; //Warning buzzer outpin pin B. //Define input digital pins. int oilDpin = 10; //Input from oil pressure switch. //Characters to display floating points to the required precision on the LCD char engineHoursdisplay[15]; char rpmOutdisplay[15]; char tempOutdisplay[15]; char oilOutdisplay[15]; char voltOutdisplay[15]; char dieselOutdisplay[15]; //various constants const int oilMin = 15; //Minimum oil pressure warning value PSI. const int oilMax = 85; //Maximum oil pressure warning value PSI. const int tempMax = 105; //Maximum coolant temperature warning value C. const int voltMin = 12; //Minimum voltage warning value. const int voltMax = 15.5; //Maximum voltage warning value. const int dieselMin = 10; //Minimum fuel tank warning level value. const int ldrThreshold = 400; //ldrIn value to switch backlight on/off. Higher is darker. int buzzWarn = 0; //Sound buzzer when set to >0 (1). //Equation values. const float rpmM = 4.554; //m part of the y=mx+c linear equation for converting Analogue in to rpm displayed. const float rpmC = 215.706; //c part of the y=mx+c linear equation for rpm. //Voltage divider resistors units are 10^3ohms to minimise interger values and overflow risk. //Dimensionless as divider ratio is (voltR1+voltR2)/voltR2. //const int rpmR1 = 27; //kohms //Rpm voltage divider resistors. //const int rpmR2 = 10; //kohms const int voltR1 = 27; //kohms //Voltage sensing divider resistors. const int voltR2 = 10; //kohms const float tempB = 0.000786; //B multiplier parameter for temperature resistance curve. const float tempR = 0.000942; //r offset parameter for temperature resistance curve. float tempR2 = 0.0; //calculated resistance of temperature sender. const float tempR1 = 220.0; //voltage divider resistor for temp sender. const float oilM = -0.243; //M multiplier for oil pressure linear equation const float oilC = 178.543; //C offset for oil pressure linear equation float oilR2 = 0.0; //Calculated resistance of oil sender. const float oilR1 = 100.0; //voltage divider resistor for oil sender. const float dieselM = 1; //M multiplier for diesel level linear equation. const float dieselC = 0; //C offset for diesel level linear equation. float dieselR2 = 0.0; //Calculated resistance of diesel sender. const float dieselR1 = 100.0; //Voltage divider resistance for diesel level oil sender. void setup() { // put your setup code here, to run once: // Define digital outputs for warning LED's and buzzer. pinMode(oilWarn, OUTPUT); pinMode(tempWarn, OUTPUT); pinMode(voltWarn, OUTPUT); pinMode(dieselWarn, OUTPUT); pinMode(buzzwarnA, OUTPUT); pinMode(buzzwarnB, OUTPUT); //Define digital input pin for pinMode(oilDpin, INPUT); //External pullup resistor used. //Initialise warning LED's and Buzzer. digitalWrite(oilWarn, LOW); //lOW turns it off. digitalWrite(tempWarn, LOW); digitalWrite(voltWarn, LOW); digitalWrite(dieselWarn, LOW); digitalWrite(buzzwarnA, LOW); digitalWrite(buzzwarnB, LOW); // initialise the lcd lcd.init(); //3 blinks of LCD backlight and LED's, except alternator warning which is 12V and seperate. for (int i = 0; i < 3; i++) { lcd.backlight(); digitalWrite(oilWarn, HIGH); digitalWrite(tempWarn, HIGH); digitalWrite(voltWarn, HIGH); digitalWrite(dieselWarn, HIGH); delay(250); lcd.noBacklight(); digitalWrite(oilWarn, LOW); digitalWrite(tempWarn, LOW); digitalWrite(voltWarn, LOW); digitalWrite(dieselWarn, LOW); delay(250); } //Get current engine hours. EEPROM.get(hoursAddress, engineHours); //Initialise time counter for engine hour updating. uint32_t ts1 = millis(); /*//Debug serial port monitoring. Comment out for production. //Must have laptop connected and serial monitor running if uncommented, //or the Arduino hangs at this point waiting for the serial port to connect. Serial.begin (115200); // Leonardo: wait for serial port to connect while (!Serial) { }*/ } void loop() { // put your main code here, to run repeatedly: //Read analog sensors. tempIn = analogRead(tempPin); oilIn = analogRead(oilPin); voltIn = analogRead(voltPin); dieselIn = analogRead(dieselPin); rpmIn = analogRead(rpmPin); ldrIn = analogRead(ldrPin); //Read digital sensors oilDin = digitalRead(oilDpin); //Check engine hours count and update every 0.1 hour. uint32_t ts2 = millis(); if (ts2 - ts1 >= 360000) { ts1 = ts2; EEPROM.put(hoursAddress, engineHours + 0.1); engineHours = engineHours + 0.1; } //Calculations for engine voltage, oil pressure, water temperature, LDR and RPM. //Use *.0 for constants to force calculation in to floating point mode, except LDR where it doesn't matter. voltOut = voltIn * 5.0 * (voltR1 + voltR2) / (voltR2 * 1023.0); //Engine voltage calculation. Resistor based voltage divider. //Calculate oil sender resistance. //oilR2 = oilR1 * 1023 / (1023 - oilIn); oilOut = oilM * oilIn + oilC; //Oil pressure calculation. //Calculate temp sender resistance. tempR2 = tempR1 * 1023 / (1023 - tempIn); tempOut = (1 / ((tempB * log10(tempR2)) + tempR)) - 273.0; //Temperature calculation. //Calculate fuel sender resistance. dieselR2 = dieselR1 * 1023 / (1023 - dieselIn); dieselOut = dieselIn * dieselM + dieselC; //Fuel level calculation. Awaiting calibration data. //RPM calculation. Linear equation. rpmOut = rpmM * rpmIn + rpmC; //Set LCD backlight according to the ambient light level detected by the LDR. if (ldrIn <= ldrThreshold) { lcd.backlight(); } else { lcd.noBacklight(); } //Convert floating point values to the required precision and put them in to strings to display on the LCD. dtostrf(engineHours, 5, 1, engineHoursdisplay); dtostrf(rpmOut, 4, 0, rpmOutdisplay); dtostrf(tempOut, 3, 0, tempOutdisplay); dtostrf(oilOut, 3, 0, oilOutdisplay); dtostrf(voltOut, 2, 1, voltOutdisplay); dtostrf(dieselOut, 3, 0, dieselOutdisplay); //Debug readout to serial monitor. /*Serial.print("oilDpin "); Serial.println(oilDpin); Serial.print("Engine Hours "); Serial.println(engineHoursdisplay); Serial.print("RPM In "); Serial.print(rpmIn); Serial.print(" Out "); Serial.print(rpmOut); Serial.print(" Display "); Serial.println(rpmOutdisplay); Serial.print("Temperature In "); Serial.print(tempIn); Serial.print(" Out "); Serial.print(tempOut); Serial.print(" Display "); Serial.println(tempOutdisplay); Serial.print("Oil Press In "); Serial.print(oilIn); Serial.print(" Out "); Serial.print(oilOut); Serial.print(" Display "); Serial.println(oilOutdisplay); Serial.print("Voltage In"); Serial.print(voltIn); Serial.print(" Out "); Serial.print(voltOut); Serial.print(" Display "); Serial.println(voltOutdisplay); Serial.print("LDR In "); Serial.println(ldrIn); //Serial.print("OilIn "); //Serial.println(oilIn); //Serial.print("Oil R1 "); //Serial.println(oilR1); //Serial.print("Oil Sender Resistance OilR2 "); //Serial.println(oilR2); Serial.print("tempIn "); Serial.println(tempIn); Serial.print("tempR1 "); Serial.println(tempR1); Serial.print("Temp Sender Resistance tempR2 "); Serial.println(tempR2); delay(4000); //Delay so above can be read.*/ //Display results on the LCD. lcd.clear(); //Display RPM. lcd.setCursor(0, 0); lcd.print("Engine"); lcd.setCursor(7, 0); if (rpmOut < 300) { lcd.print("0"); } //Set display RPM to 0 if it is low to get round tolerance errors with a stopped engine. else { lcd.print(rpmOutdisplay); } lcd.setCursor(11, 0); lcd.print("rpm"); /*//Display fuel level. lcd.setCursor(16,0); lcd.print(dieselOutdisplay); lcd.setCursor(19,0); lcd.print("l");*/ //Display water temperature. lcd.setCursor(0, 1); lcd.print("Water"); lcd.setCursor(7, 1); lcd.print(tempOutdisplay); lcd.setCursor(11, 1); lcd.print("degC"); //Display oil pressure. lcd.setCursor(0, 2); lcd.print("Oil"); lcd.setCursor(7, 2); lcd.print(oilOutdisplay); lcd.setCursor(11, 2); lcd.print("PSI"); //Display Voltage lcd.setCursor(0, 3); lcd.print(voltOutdisplay); lcd.setCursor(4, 3); lcd.print("V"); //Display engine hours. lcd.setCursor(7, 3); lcd.print(engineHoursdisplay); lcd.setCursor(14, 3); lcd.print("Hrs"); //Warning LED's, LCD display and buzzer for engine problems with voltage, oil, water, or diesel tank. //Voltage if (voltOut > voltMax) { digitalWrite(voltWarn, HIGH); lcd.setCursor(14, 3); lcd.print("*HIGH*"); buzzWarn = 1; //sound buzzer } else { digitalWrite(voltWarn, LOW); } if (voltOut < voltMin) { digitalWrite(voltWarn, HIGH); lcd.setCursor(14, 3); lcd.print("*LOW*"); buzzWarn = 1; } else { digitalWrite(voltWarn, LOW); } //Oil Pressure if ((oilOut > oilMax) && (rpmOut < 200)) { digitalWrite(oilWarn, HIGH); lcd.setCursor(14, 2); lcd.print("*HIGH*"); } else { digitalWrite(oilWarn, LOW); } if (((oilOut < oilMin) || (oilDin = LOW)) && (rpmOut < 200)) { digitalWrite(oilWarn, HIGH); lcd.setCursor(14, 2); lcd.print("*LOW*"); } else { digitalWrite(oilWarn, LOW); } if ((oilOut > oilMax) && (rpmOut >= 200)) { digitalWrite(oilWarn, HIGH); lcd.setCursor(14, 2); lcd.print("*HIGH*"); buzzWarn = 1; } else { digitalWrite(oilWarn, LOW); } if (((oilOut < oilMin) || (oilDin = LOW)) && (rpmOut >= 200)) { digitalWrite(oilWarn, HIGH); lcd.setCursor(14, 2); lcd.print("*LOW*"); buzzWarn = 1; } else { digitalWrite(oilWarn, LOW); } //Water temperature. if (tempOut > tempMax) { digitalWrite(tempWarn, HIGH); lcd.setCursor(14, 1); lcd.print("*HIGH*"); buzzWarn = 1; } else { digitalWrite(tempWarn, LOW); } /*//Diesel fuel low level in the tank. if(dieselOut < dieselMin){ digitalWrite(dieselWarn, LOW); }*/ //Either sound warning buzzer delay 1sec. if (buzzWarn > 0) { buzz(); } else { delay(1000); // update each second } buzzWarn = 0; } //Warning Buzzer. Set up buzz function with 4kHz frequency for half sec, delay half sec. void buzz() { long elapsed_time = 0; while (elapsed_time < 500000) { digitalWrite(buzzwarnA, HIGH); digitalWrite(buzzwarnB, LOW); delayMicroseconds(125); digitalWrite(buzzwarnA, LOW); digitalWrite(buzzwarnB, HIGH); delayMicroseconds(125); elapsed_time += 250; } delay(500); }
  15. Jen-in-Wellies

    Lifeboat Conversion

    I'd second what has been said on getting as much done as you can before moving on. With your stuff on board any work will take several times as long as the first and last tasks will be moving stuff out the way, then moving it back again. Worse still, you may get the urge to go cruising instead of fitting out and then the fit out work stops altogether! Happened to me. These style of lifeboats give you a good hull and a well maintained engine and basic electrical system for a very good price. They aren't really the ideal shape for either canals, or living aboard, but I can see why people go for them. They can be made in to something nice and a bit different from the usual sewer tube, or yoghurt pot. Jen
×
