1 hour ago, Bee said:
Licence and winter moorings are frequently about 1/3 of the UK and Belgium and Holland can be even less.
The downside is that you'll usually pay an arm and a leg for water and electricity in Belgium. Typically 1€ per kWh or 100 L. It's usually included in the fees in France. Remember that Belgium operates as two countries: the licence in Flanders is fairly cheap, and free in Wallonia. I've not been, but I think it's even more complicated in the Netherlands.
Also, often the electricity supply is centre-tapped in Belgium which is confusing. One should not rely on neutral being on the "proper" pole of the connector. It's useful to have a phase-reversing adaptor (a pair of connectors cross-connected) and a socket tester - like https://www.screwfix.com/p/lap-ms6860d-socket-tester/91596
-
1 hour ago, J R ALSOP said:
Gas bottle connections are also different.
I think adaptors are available, but easier to buy a new regulator.
-
8 hours ago, lifeintheslowlanes said:
So a self pump out pump to drop the tank out could be useful then... I had read about the length limits on pontoons and luckily being 45ft shouldn't have too much of an issue with that. Someone else had recommended joining the DBA too for info (and at £35 I figure it's probably worthwhile). Cheers for the advice!
If you've got a holding tank, you'll need to be able to pump out yourself. Ideally connect it permanently so you don't have to dump it all in one place!
The DBA is worth the fee just to access the online waterways guides. They are updated by members and are generally a comprehensive and accurate list of where it is feasible to moor, as well as facilities and costs.
Another thing: in France diesel is not seen much in marinas and is usually expensive. Most boats carry cans to fill up at service stations.
VHF is useful on the bigger waterways, and essential if you are going into Belgium.
There are specific regulations, and you can expect to be inspected occasionally. Fire extinguishers and lifejackets must be in date. You need a bucket on a rope for fires! Look at the DBA knowledge guides (but remember that a lot of the more complicated stuff relates to boats over 20m). I'm not sure if nav lights are compulsory or not (if not traveling at night).
-
Hose connectors are nearly all bog standard BSP.
Shore line connectors are nearly all the usual 16A type.
It is very useful to have a couple of 30m mooring lines and some very big mooring pins.
Main difference is that nearly all toilet waste goes over the side. I've only seen one pumpout in France. Elsan disposal can be found at municipal camper van sites which are often waterside.
On many waterways the only feasible mooring is at dedicated spaces. Mooring online in the middle of nowhere can be impossible due to depth, rocky banks or wash from commercials.
A narrowboat is not ideal. Many moorings are on pontoons and limited to 15 m or less. It can be done though.
More specific advice on the DBA website but you need to join to access their very useful waterways guides and forum.
Martin/
-
Possibly a 610mm shower tray which is the current standard size. Google will find lots. Something may suit.
-
2 hours ago, Keeping Up said:
I once had the strainer on my pump break. The contents of the water tank deposited itself in the bilges & the water came up over the rear cabin floor, but up in the lounge we were unaware until the next time the kitchen tap was turned on at which point the pump wouldn't stop.
Ours decided to separate into two halves recently. Held together with a bayonet fitting but without the clicky bit at the end. It dumped 250 L into the bilge.
-
1 hour ago, alan_fincher said:
Last time we used Cooke and Lewis units from B&Q, which were completely satisfactory. However B&Q are phasing them out and replacing with an alternate that seems to be inferior in every way, and gets crap reviews on their website, (and I mean really crap reviews, not offset by any good ones.
That's a pity, the C&L weren't bad for the price. I've just fitted a couple in my house. We were lucky to have bought just in time. It's worth adding some PVA to the joints to make them sturdier.
-
It might be feasible if installed as an adjunct to a stove, and would make the boat feel very comfortable. Easier to fit on a new build. Maybe just fit it up the middle 1 m of the boat (assuming a narrowboat) as the edges are usually furniture. The ballast goes up the edges. Build a Celotex wall to separate the centre section from the ballast area, and line the baseplate with Celotex.
Typcial heating mat is 150 - 200 W/m^2. 50 mm Celotex has an R-value of 2.25 m^2 K / W so a deltaT of say 40 K water to heat mat would only lose about 17 W/m^2 to the water, anything left would warm your feet. 10 m^2 of 150 W/m^2 would therefore put over 1300 W into the boat. Not enough to keep it fully heated but it would certainly make the boat feel more comfortable.
Domestic underfloor relies on a low heat input over a large area. A narrowboat is only the area of a small room in a house.
-
I'd try to keep it simple.
Tank H has webasto and engine
Tank V has solar (with its own pump and controller) and spare coil.
Fit the Webasto outlet with a three way valve (including midway option) to feed H, V spare coil or both.
Cold feed to V comes from hot outlet of H. DHW feed comes from V.
Normal operation has Webasto going to V or use solar in V.
Bathnight has Webasto powering H (and V if solar hasn't done much).
It sounds as if you don't use the engine much, but otherwise you could arrange a small recirculation pump from hot side of V to cold side of H (with a NRV in the cold feed to H and an expansion tank) to get hot water to V.
I don't know if you can get three-way valves for 12 V with a midway option, but otherwise take the actuator off and operate it manually (Womanually? Gender-non-specificually?)
Some clever Arduino programming with sensors could help, or get very confusing!
Martin/
-
"Hardly no cavitation"??
-
1
-
-
6 minutes ago, Tash and Bex said:
what about a collector network directly on the baseplate, a given amount of reflective insulation on top to create a thermal barrier, then run the heating matrix through those bricks with holes in them in lieu of a more conventional frog? Always good to make stuff work for a living on a boat, and it would make my ballast less "passive"!
That is the idea that's doing the rounds of the old grey matter atm, but I haven't even started adding numbers to it!
Might work if you've got enough space under the floor. However (without doing any sums) you would need a thick insulation layer as the area used over the baseplate would be large. Otherwise you'll be circulating heat from one side to t'other.
Molten salt storage? ?
-
13 minutes ago, Tash and Bex said:
well I wouldn't exactly be all electric, and a decent cocooned generator should keep up with a heat pump I would have thought, particularly if i were to use ballast as a thermal store.....early days and depends on whether I take the plunge and go wide beam. but between a generator and 4kw of solar I think it's worth looking into
If you've got that much electrical power then no problem! You'll have a large bath tank as a thermal store! Water has the highest thermal capacity of anything readily available, although it would be interesting to do a conceptual design using parafin wax as a thermal store using its latent heat of fusion.
-
16 minutes ago, Tash and Bex said:
do you know (unrelated to the bath) I was just looking into the use of a heat pump for heating an all electric (hybrid I guess) boat.
It's tempting, but for any reasonable heat output the electrical consumption (assuming that you go the more conventional route) gets a bit scary. A CoP of 4 would be good in practice even if the theoretical maximum is higher, you might be able to do better with a reliable heat sink like a canal and by keeping the output temperature low. Gas-fired absorption heat pumps are available, but you said somewhere that you don't want gas and you'll still need some electric for running mechanical pumps. (I'm looking at heat pumps for domestic use. Glad that I kept my old thermodynamics text book!)
-
I'd bet there's no dip tube inside the tank.
Edit: ignore that, I'd missed three pages of discussion!
-
One could use a heat pump to warm the tank, with the canal water as heat source (heat conducted through the base plate). It would need a compressor for a more conventional system, but that could be mechanically powered using e.g. a gym stepping machine. After a couple of hours exercise a nice hot bath would be welcome. A diesel fired absorption heat pump would also work but I don't think anyone makes them. A market opportunity?
-
I slapped some Zinsser all coat exterior black on our gunwales last year. Went on easily, covered well, looks good. From Screwfix. Supposed to be satin but it's fairly glossy.
-
Having towed Vanessa from Abingdon to Eynsham, I can vouch that she is (mostly!) harmless and good company! It was a pleasant voyage, aside from a minor collision with Godstow Bridge in a strong cross wind and a couple of bumps going into locks. She was alongside our nb most of the way, other than some narrow bridge 'oles and all of the locks above Iffley where we towed her behind (oo-err!) I would have been happy to help again, but other commitments in the next few weeks make it unlikely.
-
3
-
-
1 hour ago, Tash and Bex said:
Maybe I will stay a while after all, at least I might be able to help a few people in a less judgemental way.
Please stay! You have a nice sense of humour. Ignore the r-soles.
-
If, is suggested elsewhere, you use the bath as your heat store, you could insulate the surface with tesselating plastic ducks. Is that sufficiently out of the box?
2 minutes ago, Paul C said:Its the Poiseuille Equation, I think? That's assuming the flow remains laminar (I think it will......but you can always check by calculating the Reynolds number).
That tells you the delta P for laminar flow in a pipe. I've lost the plot as to what you're trying to calculate!
-
33 minutes ago, Boater Sam said:
You would need a significant length of 10mm pipe to achieve sufficient surface area for heat transfer on the rate that a Webasto kicks it out. Nice idea but it requires more design than has been proposed. 10mm pipe is far too small for the required flow rate in the Webasto heat exchanger matrix.
I said I'd not done the heat transfer calcs. However, a flow rate through the 10 mm secondary of 2 L / min with a delta T of 40 C would take 5.6 kW of heat. Based on experience with a very differently configured heat exchanger I use for cooling wort with about 1 m of 10 mm pipe, the heat transfer rate probably isn't miles adrift.
-
2 minutes ago, Boater Sam said:
Coaxial plumbing is difficult to arrange, requires special tee pieces.
Plenty of c/f heat exchangers are home-made for brewing purposes. Just needs some imagination, and Bex doesn't seem short of that ?
e.g. 10 x 15 x 15 tee at each end, with a short length of 15 mm Cu pipe into plastic fittings. Ream out the 10mm end so that the pipe will pass through.
-
You could save a second Webasto by putting a small c/f h/x between your existing Webasto and calorifier coil with a switched pump that feeds secondary side water around your bathtime tank (or bath). It would have no effect on the normal operation of heating the calorifier. Without doing the heat transfer calculations, maybe a metre or so of 10 mm copper tube on the secondary inside 15 mm plastic tube carrying the primary, the whole lot insulated and coiled.
Martin/
-
42 minutes ago, bizzard said:
Tinkin outside da box-boat. Mount bath upon bricks on towpath. Fill with canal water. Light a fire of sticks beneath it. Wait one hour precisely to heat up. Jump in with toy boat or duck.
When I were a lad, we had a galvanised steel bath. Filled it from kettle and saucepans on t'gas cooker every Friday night. Youth of today don't know they've been born etc...
-
53 minutes ago, Tash and Bex said:
I've just looked at the capacity, which it clams is 210l, so no allowance for displacement,
Bath with a friend and double the displacement ?
210 L is a lot of water in a bath unless you want to swim lengths. I reckon we use less than 100 L in a corner bath at home.
Shipping a narrowboat to France?
in General Boating
Posted
All good points. However wash from the big boats is not really a problem when moving and they are mostly considerate. Mostly. Drag when moored is more of an issue. There have also been a lot of closures in recent years due to lack of water on the smaller and sometimes bigger canals.
Another thing to consider is how to operate locks. Are you single handing? Some of the locks are deep and need lines moved as you go up. You'll need to work out a procedure for going up and down. The usual method is to take a line from the front to a bollard and keep tension on it with the engine. Harder without a crew to control the rope.
