[Gybe Ho]

When planning the cabinet layout I arranged the hot components to avoid convected heat warming another hot component above. I also intend to avoid letting heat generated in the batteries wafting upwards into the main cabinet above as per Victron standard advice even though I cannot afford their lithium batteries.



I have a question about ducting to exhaust heat from the cabinet,



Given 3 heat sources below, the most testing scenario would be when moored in a marina on a hot summers day to do a Tesla style rapid charge of say 25kWh. If the marina bollard can cope, the Multiplus would charge at 4kW, at the same time the solar might be generating be at max headline panel rate of 1.7kW and if many of 24v domestic circuits are on the DC/DC convertor could be working at 400 watts.



Invertor/Charger 4kW at 91% efficiency = 360

MPPT 1.7kW at 95% efficiency = 87

DC/DC 0.4kW at 87% efficiency = 52



By my calcs the worst case heat generation in the cabinet would be 500 watts and that requires mechanical removal.



Does anyone recognize the ducting shown in the first 30 seconds in this video? It looks like a 100mm square fan connected to a slim box shaped duct.



https://www.youtube.com/watch?v=6upMwO-x8so





[truckcab79]

9 minutes ago, Gybe Ho said:

When planning the cabinet layout I arranged the hot components to avoid convected heat warming another hot component above. I also intend to avoid letting heat generated in the batteries wafting upwards into the main cabinet above as per Victron standard advice even though I cannot afford their lithium batteries.



I have a question about ducting to exhaust heat from the cabinet,



Given 3 heat sources below, the most testing scenario would be when moored in a marina on a hot summers day to do a Tesla style rapid charge of say 25kWh. If the marina bollard can cope, the Multiplus would charge at 4kW, at the same time the solar might be generating be at max headline panel rate of 1.7kW and if many of 24v domestic circuits are on the DC/DC convertor could be working at 400 watts.



Invertor/Charger 4kW at 91% efficiency = 360

MPPT 1.7kW at 95% efficiency = 87

DC/DC 0.4kW at 87% efficiency = 52



By my calcs the worst case heat generation in the cabinet would be 500 watts and that requires mechanical removal.



Does anyone recognize the ducting shown in the first 30 seconds in this video? It looks like a 100mm square fan connected to a slim box shaped duct.



https://www.youtube.com/watch?v=6upMwO-x8so







My respect to you for endeavouring to keep your thread on track. I will refrain from posting more on it as I don’t want to be responsible for more distraction and another ruined thread.

All the best.





9 minutes ago, Gybe Ho said:

When planning the cabinet layout I arranged the hot components to avoid convected heat warming another hot component above. I also intend to avoid letting heat generated in the batteries wafting upwards into the main cabinet above as per Victron standard advice even though I cannot afford their lithium batteries.



I have a question about ducting to exhaust heat from the cabinet,



Given 3 heat sources below, the most testing scenario would be when moored in a marina on a hot summers day to do a Tesla style rapid charge of say 25kWh. If the marina bollard can cope, the Multiplus would charge at 4kW, at the same time the solar might be generating be at max headline panel rate of 1.7kW and if many of 24v domestic circuits are on the DC/DC convertor could be working at 400 watts.



Invertor/Charger 4kW at 91% efficiency = 360

MPPT 1.7kW at 95% efficiency = 87

DC/DC 0.4kW at 87% efficiency = 52



By my calcs the worst case heat generation in the cabinet would be 500 watts and that requires mechanical removal.



Does anyone recognize the ducting shown in the first 30 seconds in this video? It looks like a 100mm square fan connected to a slim box shaped duct.



https://www.youtube.com/watch?v=6upMwO-x8so





Is it not just maxi trunking 100mmx100mm or skirting trunking 100mmx50mm?  TLC Direct will have it if so.

Edited January 5, 2025 by truckcab79

[ditchcrawler]

14 minutes ago, Gybe Ho said:

 . If the marina bollard can cope, the Multiplus would charge at 4kW,





You would be very lucky to get that, I take it you are planning for a 32 amp shore connection. Most marinas you would be lucky to get the rated 16 amps at 230 volts

[IanD]

17 minutes ago, Gybe Ho said:

When planning the cabinet layout I arranged the hot components to avoid convected heat warming another hot component above. I also intend to avoid letting heat generated in the batteries wafting upwards into the main cabinet above as per Victron standard advice even though I cannot afford their lithium batteries.



I have a question about ducting to exhaust heat from the cabinet,



Given 3 heat sources below, the most testing scenario would be when moored in a marina on a hot summers day to do a Tesla style rapid charge of say 25kWh. If the marina bollard can cope, the Multiplus would charge at 4kW, at the same time the solar might be generating be at max headline panel rate of 1.7kW and if many of 24v domestic circuits are on the DC/DC convertor could be working at 400 watts.



Invertor/Charger 4kW at 91% efficiency = 360

MPPT 1.7kW at 95% efficiency = 87

DC/DC 0.4kW at 87% efficiency = 52



By my calcs the worst case heat generation in the cabinet would be 500 watts and that requires mechanical removal.



Does anyone recognize the ducting shown in the first 30 seconds in this video? It looks like a 100mm square fan connected to a slim box shaped duct.



https://www.youtube.com/watch?v=6upMwO-x8so





I have 140mm 2000rpm fans for cooling my electrical cabinet, with 125mm bore insulated flexible ducting to the outside world.



One fan blowing cold air in (plus a passive exit duct) has not provided enough airflow, the air temperature inside the cabinet next to the Quattro air intake can reach more than 40C (+15C temperature rise) after several hours of generator use for charging (this is what gets the Quattro hottest). I'm going to add a second fan on the exhaust side, this should roughly triple the airflow and drop the temperature rise to about 5C.



(more than doubled since the cabinet is not airtight, and some of the cool incoming air leaks out past the doors when the generator is running and pulling air in from outside via a thire 125mm duct)

[Gybe Ho]

13 minutes ago, ditchcrawler said:

You would be very lucky to get that





I thought that might be the case. I was planning cabinet cooling for a worst case scenario. The Multplus can be configured to draw at lower rate. My expectations do not exceed 16 amps which is close enough to 4kW.



28 minutes ago, truckcab79 said:



Is it not just maxi trunking 100mmx100mm or skirting trunking 100mmx50mm?  TLC Direct will have it if so.





Not sure I have not needed ducting before. From the video I got the impression the overhanging fan is a snug fit and part of an integrated heat extraction ducting system.

Edited January 5, 2025 by Gybe Ho

[IanD]

8 minutes ago, Gybe Ho said:



I thought that might be the case. I was planning cabinet cooling for a worst case scenario. The Multplus can be configured to draw at lower rate. My expectations do not exceed 16 amps which is close enough to 4kW.



Not sure I have not needed ducting before. From the video I got the impression the overhanging fan is a snug fit and part of an integrated heat extraction ducting system.



I looked at using rigid built-in ducting and rejected the idea. Flexible ducting is cheap and far easier to use and connect up to circular air vents in the hull, like these.





[Paul C]

1 hour ago, Gybe Ho said:





I have a question about ducting to exhaust heat from the cabinet,









Personally, if I were designing a boat from scratch, I'd duct the air from the cabinet to the outside. The reason being, if there's a fire (which is more likely than other areas, since its full of electrics) it would minimise the spread.

[IanD]

10 minutes ago, Paul C said:



Personally, if I were designing a boat from scratch, I'd duct the air from the cabinet to the outside. The reason being, if there's a fire (which is more likely than other areas, since its full of electrics) it would minimise the spread.

Also air from outside is usually cooler. I have a cold air inlet vent at one end of the cabinet (behind the IT) and a hot air exhaust vent at the other (next to the hot air from the top of the Quattro), both ducted to the outside. All this (and generator, diesel boiler, calorifier, motor, batteries, MPPTs...) is in the engineering space under the stern deck where an engine would be, with a steel bulkhead between this and the living space.



The only electrics inside the boat cabin are the Cerbo GX and display and the AC/DC distribution panels.

Edited January 5, 2025 by IanD

[jim mitchell]

Gybe Ho , Do you actually need the panel C   acting as a divider, moving the MPPT up 75 mm (all its connections are bottom entry?),  and then  move the Multi left by 100mm and if you reposition the isolater that's just left of the 24V switch panel (higher ?) the DC to DC and Cerbo would comfortably fit on the combined Panels B/D  which would leave a very roomy electrics area and simply airflow for cooling perhaps via standard trunking 100 x 100mm run across the top  with 1, 2. or even 3 fans to "pull" hot air and direct it to the Galley _ the fans could be wired to run only when a unit needs cooling eg  one switched (on the end ) when MPPT operates , one above the Multiplus etc

[Gybe Ho]

4 hours ago, Paul C said:



Personally, if I were designing a boat from scratch, I'd duct the air from the cabinet to the outside. The reason being, if there's a fire (which is more likely than other areas, since its full of electrics) it would minimise the spread.



Yes I went through the same thought process. The factors that swayed me were free heat from the cabinet fed into the galley, installation simplicity and concerns of water ingress in challenging locks. Having recently seen Mrs Mindful's traumatic decent of the deep lock at the eastern end of the Rochdale, that involved an urgent reflooding the lock, I am wary of creating a conduit for Niagara falls direct into the electric cabinet.



The Victron stuff is heat tolerant,  it just looses efficiency.



On the other side I am concerned about venting electrical hot circuit smells into the galley way be anything ignites.



Mrs Mindful's entertaining lock decent in her 60 footer = https://youtu.be/4NgILOZxtac?t=1260





4 hours ago, Paul C said:



The reason being, if there's a fire (which is more likely than other areas, since its full of electrics) it would minimise the spread.





You are right all those amps and stored kWh are a big fire risk. I will need to run some high amp soak tests and examine all joints with an IR temperature gun or FLIR camera. I understand I will need to retorque all the major connections after initial use. During the build I will have to find some method to apply a 10kW load at the end of the motor supply cables so that I can monitor the whole setup under sustained load.



In general some heat extraction in the cabinet will put me at an advantage to most narrowboat setups where increasing electrical complexity is stuffed into a small locker and fingers are crossed that the heat will find a way out.

4 hours ago, IanD said:

Also air from outside is usually cooler. I have a cold air inlet vent at one end of the cabinet (behind the IT) and a hot air exhaust vent at the other (next to the hot air from the top of the Quattro), both ducted to the outside.



Cool air input... not an option I had considered. I hope that with  pram hood over the cruiser stern and the Oakum stile inner galley door I will be able to let cool air into the cabinet by leaving the sliding main hatch open.

Edited January 6, 2025 by Gybe Ho

[Gybe Ho]

46 minutes ago, jim mitchell said:

Gybe Ho , Do you actually need the panel C   acting as a divider, moving the MPPT up 75 mm (all its connections are bottom entry?),  and then  move the Multi left by 100mm and if you reposition the isolater that's just left of the 24V switch panel (higher ?) the DC to DC and Cerbo would comfortably fit on the combined Panels B/D  which would leave a very roomy electrics area and simply airflow for cooling perhaps via standard trunking 100 x 100mm run across the top  with 1, 2. or even 3 fans to "pull" hot air and direct it to the Galley _ the fans could be wired to run only when a unit needs cooling eg  one switched (on the end ) when MPPT operates , one above the Multiplus etc



I will have to think about your post but as a FYI the following videos demonstrate the layout I want. In this video you will see that panel C is a divide to create the panel D inset with the switch panels above and a seat below. My battery bank will be higher so not seat.



https://www.youtube.com/watch?v=y5pS34lmA5A&t=479s



https://www.youtube.com/watch?v=y5pS34lmA5A&t=1256s
